Wenglor IB040BM46VD8 Inductive Sensor

IB040BM46VD8
Wenglor

The Wenglor IB040BM46VD8 is an inductive sensor designed for non-contact detection of metallic objects, featuring a 4 mm switching distance and flush mounting capability. CR

$20.00
Tax excluded
Quantity
Last items in stock
3 Items

Ask about the product on WhatsApp
Make an Offer

Your Offer is sent.

Your Offer is accepted, please check your inbox.

  • Use dot instead of comma
  •     *Required Fields

Loading

  Security policy

We offer many payment options to make your purchasing experience secure, easy and flexible.

  Delivery policy

In-stock products: Same day shipping Mon. through Fri. by 6:00 pm EST.

  Return policy

90-days money back guarantee

Description

The IB040BM46VD8 operates with a supply voltage range of 10 to 30 V DC and consumes less than 6 mA at 24 V. It offers a switching frequency of 700 Hz and functions within a temperature range of -25 to 80°C. The sensor provides a PNP normally closed (NC) output with a maximum switching current of 200 mA and a voltage drop of less than 2.5 V. It includes protections against short circuits, reverse polarity, and overload, ensuring reliable performance in various industrial environments. The housing is made of nickel-plated brass, fully encapsulated to achieve an IP67 protection rating, and features an M8 × 1; 3-pin connection. The sensor's compact design, with a weight of 11 g, facilitates easy integration into existing systems.

Features:

  • Switching distance: 4 mm
  • Flush mounting
  • Supply voltage: 10 to 30 V DC
  • Current consumption: < 6 mA at 24 V
  • Switching frequency: 700 Hz
  • Temperature range: -25 to 80°C
  • Switching output: PNP NC
  • Switching current: 200 mA
  • Voltage drop: < 2.5 V
  • Short circuit, reverse polarity, and overload protection
  • Housing material: Nickel-plated brass
  • Degree of protection: IP67
  • Connection: M8 × 1; 3-pin
  • Weight: 11 g
Product Details
IB040BM46VD8
3 Items

Specific References

MPN
4500040481
